Telescopic Tipper Cylinders

5 sub-categories · 69 products

2 to 5-stage telescopic cylinders for trailers and tippers.

← All categories

2-stage telescopic cylinders 7

Stock code	Stages	Closed length L (cm)	Capacity (t)	Stroke H (mm)	Port	45 mm	60 mm	75 mm	90 mm	105 mm
ORK-TLS-4000	2	43	2	550	5/8	*	*	*
ORK-TLS-4001	2	50	2	700	5/8	*	*	*
ORK-TLS-4002	2	64	5	910	5/8			*	*	*
ORK-TLS-4003	2	74	5	1110	5/8			*	*	*
ORK-TLS-4004	2	80	5	1230	5/8			*	*	*
ORK-TLS-4005	2	90	5	1430	5/8			*	*	*
ORK-TLS-4006	2	100	5	1630	5/8			*	*	*

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.

Stock code	Stages	Closed length L (cm)	Capacity (t)	Stroke H (mm)	Port	60 mm	75 mm	90 mm	105 mm	125 mm	145 mm
ORK-TLS-4007	3	64	5	1360	5/8	*	*	*	*
ORK-TLS-4008	3	74	5	1660	5/8	*	*	*	*
ORK-TLS-4009	3	80	5	1840	5/8	*	*	*	*
ORK-TLS-4010	3	90	5	2140	5/8	*	*	*	*
ORK-TLS-4011	3	100	5	2440	5/8	*	*	*	*
ORK-TLS-4012	3	64	10	1360	3/4		*	*	*	*
ORK-TLS-4013	3	74	10	1660	3/4		*	*	*	*
ORK-TLS-4014	3	80	10	1840	3/4		*	*	*	*
ORK-TLS-4015	3	85	10	1990	3/4		*	*	*	*
ORK-TLS-4016	3	90	10	2140	3/4		*	*	*	*
ORK-TLS-4017	3	100	10	2440	3/4		*	*	*	*
ORK-TLS-4018	3	64	15	1370	3/4			*	*	*	*
ORK-TLS-4019	3	74	15	1670	3/4			*	*	*	*
ORK-TLS-4020	3	80	15	1850	3/4			*	*	*	*
ORK-TLS-4021	3	85	15	2000	3/4			*	*	*	*
ORK-TLS-4022	3	90	15	2150	3/4			*	*	*	*
ORK-TLS-4023	3	100	15	2450	3/4			*	*	*	*

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.

Stock code	Stages	Closed length L (cm)	Capacity (t)	Stroke H (mm)	Port	60 mm	75 mm	90 mm	105 mm	125 mm	145 mm	170 mm
ORK-TLS-4024	4	64	10	1810	3/4	*	*	*	*	*
ORK-TLS-4025	4	74	10	2210	3/4	*	*	*	*	*
ORK-TLS-4026	4	80	10	2450	3/4	*	*	*	*	*
ORK-TLS-4027	4	85	10	2650	3/4	*	*	*	*	*
ORK-TLS-4028	4	90	10	2850	3/4	*	*	*	*	*
ORK-TLS-4029	4	100	10	3250	3/4	*	*	*	*	*
ORK-TLS-4030	4	64	15	1820	3/4		*	*	*	*	*
ORK-TLS-4031	4	74	15	2220	3/4		*	*	*	*	*
ORK-TLS-4032	4	80	15	2460	3/4		*	*	*	*	*
ORK-TLS-4033	4	85	15	2660	3/4		*	*	*	*	*
ORK-TLS-4034	4	90	15	2860	3/4		*	*	*	*	*
ORK-TLS-4035	4	100	15	3260	3/4		*	*	*	*	*
ORK-TLS-4036	4	64	20	1810	3/4			*	*	*	*	*
ORK-TLS-4037	4	74	20	2210	3/4			*	*	*	*	*
ORK-TLS-4038	4	80	20	2450	3/4			*	*	*	*	*
ORK-TLS-4039	4	85	20	2650	3/4			*	*	*	*	*
ORK-TLS-4040	4	90	20	2850	3/4			*	*	*	*	*
ORK-TLS-4041	4	100	20	3250	3/4			*	*	*	*	*

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.

Stock code	Stages	Closed length L (cm)	Capacity (t)	Stroke H (mm)	Port	45 mm	60 mm	75 mm	90 mm	105 mm	125 mm	145 mm	170 mm
ORK-TLS-4042	5	64	10	2260	3/4	*	*	*	*	*	*
ORK-TLS-4043	5	74	10	2760	3/4	*	*	*	*	*	*
ORK-TLS-4044	5	80	10	3060	3/4	*	*	*	*	*	*
ORK-TLS-4045	5	85	10	3310	3/4	*	*	*	*	*	*
ORK-TLS-4046	5	90	10	3560	3/4	*	*	*	*	*	*
ORK-TLS-4047	5	100	10	4060	3/4	*	*	*	*	*	*
ORK-TLS-4048	5	64	15	2265	3/4		*	*	*	*	*	*
ORK-TLS-4049	5	74	15	2765	3/4		*	*	*	*	*	*
ORK-TLS-4050	5	80	15	3065	3/4		*	*	*	*	*	*
ORK-TLS-4051	5	85	15	3315	3/4		*	*	*	*	*	*
ORK-TLS-4052	5	90	15	3565	3/4		*	*	*	*	*	*
ORK-TLS-4053	5	100	15	4065	3/4		*	*	*	*	*	*
ORK-TLS-4054	5	64	20	2250	3/4			*	*	*	*	*	*
ORK-TLS-4055	5	74	20	2750	3/4			*	*	*	*	*	*
ORK-TLS-4056	5	80	20	3050	3/4			*	*	*	*	*	*
ORK-TLS-4057	5	85	20	3300	3/4			*	*	*	*	*	*
ORK-TLS-4058	5	90	20	3550	3/4			*	*	*	*	*	*
ORK-TLS-4059	5	100	20	4050	3/4			*	*	*	*	*	*

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.

Stock code	Stages	Closed length L (cm)	Capacity (t)	Stroke H (mm)	Port	45 mm	60 mm	75 mm	90 mm	105 mm	125 mm	145 mm
ORK-TLS-4060	2	38	3	465	5/8		*	*	*
ORK-TLS-4061	2	38	5	465	5/8			*	*	*
ORK-TLS-4062	4	64	10	1910	3/4		*	*	*	*	*
ORK-TLS-4063	4	64	15	1910	3/4			*	*	*	*	*
ORK-TLS-4064	5	64	10	2150	3/4	*	*	*	*	*	*
ORK-TLS-4065	5	64	15	2155	3/4		*	*	*	*	*	*
ORK-TLS-4066	5	31	10	660	3/4	*	*	*	*	*	*
ORK-TLS-4067	3	64	10	1295	3/4			*	*	*	*
ORK-TLS-4068	3	64	15	1305	3/4				*	*	*	*

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.
