Top Link Cylinders

6 sub-categories · 100 products

Hydraulic top link cylinders for tractors, 2–5 tons, with a choice of pin and head options.

← All categories

3 t top link cylinders 16

Stock code	Product type	Capacity (t)	Closed length L (cm)	Stroke H (mm)	Pin diameter C1 - C (mm)	Type	Outer diameter D1 - D (mm)	Rod diameter d (mm)
ORK-ORT-1500	TOP LINK	3	50	195	26*26-GG		60*70	40
ORK-ORT-1501	TOP LINK	3	55	245	26*26-GG		60*70	40
ORK-ORT-1502	TOP LINK	3	60	295	26*26-GG		60*70	40
ORK-ORT-1503	TOP LINK	3	68	365	26*26-GG		60*70	40
ORK-ORT-1504	TOP LINK	3	50	195	19*26-DG		60*70	40
ORK-ORT-1505	TOP LINK	3	55	245	19*26-DG		60*70	40
ORK-ORT-1506	TOP LINK	3	60	295	19*26-DG		60*70	40
ORK-ORT-1507	TOP LINK	3	68	365	19*26-DG		60*70	40
ORK-ORT-1508	TOP LINK	3	50	195	26*26-GG	VERTICAL	60*70	40
ORK-ORT-1509	TOP LINK	3	55	245	26*26-GG	VERTICAL	60*70	40
ORK-ORT-1510	TOP LINK	3	60	295	26*26-GG	VERTICAL	60*70	40
ORK-ORT-1511	TOP LINK	3	68	365	26*26-GG	VERTICAL	60*70	40
ORK-ORT-1512	TOP LINK	3	50	195	19*26-DG	VERTICAL	60*70	40
ORK-ORT-1513	TOP LINK	3	55	245	19*26-DG	VERTICAL	60*70	40
ORK-ORT-1514	TOP LINK	3	60	295	19*26-DG	VERTICAL	60*70	40
ORK-ORT-1515	TOP LINK	3	68	365	19*26-DG	VERTICAL	60*70	40

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.

Stock code	Product type	Capacity (t)	Closed length L (cm)	Stroke H (mm)	Pin diameter C1 - C (mm)	Type	Outer diameter D1 - D (mm)	Rod diameter d (mm)
ORK-ORT-1516	TOP LINK	4	50	195	26*26-GG		63*75	40
ORK-ORT-1517	TOP LINK	4	55	245	26*26-GG		63*75	40
ORK-ORT-1518	TOP LINK	4	60	295	26*26-GG		63*75	40
ORK-ORT-1519	TOP LINK	4	68	365	26*26-GG		63*75	40
ORK-ORT-1520	TOP LINK	4	50	195	19*26-DG		63*75	40
ORK-ORT-1521	TOP LINK	4	55	245	19*26-DG		63*75	40
ORK-ORT-1522	TOP LINK	4	60	295	19*26-DG		63*75	40
ORK-ORT-1523	TOP LINK	4	68	365	19*26-DG		63*75	40
ORK-ORT-1524	TOP LINK	4	50	195	26*26-GG	VERTICAL	63*75	40
ORK-ORT-1525	TOP LINK	4	55	245	26*26-GG	VERTICAL	63*75	40
ORK-ORT-1526	TOP LINK	4	60	295	26*26-GG	VERTICAL	63*75	40
ORK-ORT-1527	TOP LINK	4	68	365	26*26-GG	VERTICAL	63*75	40
ORK-ORT-1528	TOP LINK	4	50	195	19*26-DG	VERTICAL	63*75	40
ORK-ORT-1529	TOP LINK	4	55	245	19*26-DG	VERTICAL	63*75	40
ORK-ORT-1530	TOP LINK	4	60	295	19*26-DG	VERTICAL	63*75	40
ORK-ORT-1531	TOP LINK	4	68	365	19*26-DG	VERTICAL	63*75	40

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.

Stock code	Product type	Capacity (t)	Closed length L (cm)	Stroke H (mm)	Pin diameter C1 - C (mm)	Type	Outer diameter D1 - D (mm)	Rod diameter d (mm)
ORK-ORT-1532	TOP LINK	5	50	165	26*26-GG		70*80	45
ORK-ORT-1533	TOP LINK	5	55	215	26*26-GG		70*80	45
ORK-ORT-1534	TOP LINK	5	60	265	26*26-GG		70*80	45
ORK-ORT-1535	TOP LINK	5	68	345	26*26-GG		70*80	45
ORK-ORT-1536	TOP LINK	5	50	165	19*26-DG		70*80	45
ORK-ORT-1537	TOP LINK	5	55	215	19*26-DG		70*80	45
ORK-ORT-1538	TOP LINK	5	60	265	19*26-DG		70*80	45
ORK-ORT-1539	TOP LINK	5	68	345	19*26-DG		70*80	45
ORK-ORT-1540	TOP LINK	5	50	165	26*26-GG	VERTICAL	70*80	45
ORK-ORT-1541	TOP LINK	5	55	215	26*26-GG	VERTICAL	70*80	45
ORK-ORT-1542	TOP LINK	5	60	265	26*26-GG	VERTICAL	70*80	45
ORK-ORT-1543	TOP LINK	5	68	345	26*26-GG	VERTICAL	70*80	45
ORK-ORT-1544	TOP LINK	5	50	165	19*26-DG	VERTICAL	70*80	45
ORK-ORT-1545	TOP LINK	5	55	215	19*26-DG	VERTICAL	70*80	45
ORK-ORT-1546	TOP LINK	5	60	265	19*26-DG	VERTICAL	70*80	45
ORK-ORT-1547	TOP LINK	5	68	345	19*26-DG	VERTICAL	70*80	45

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.

Stock code	Product type	Capacity (t)	Closed length L (cm)	Stroke H (mm)	Pin diameter C1 - C (mm)	Type	Outer diameter D1 - D (mm)	Rod diameter d (mm)
ORK-ORT-1548	TOP LINK	3	50	145	26*26-GG	C HEAD	60*70	40
ORK-ORT-1549	TOP LINK	3	55	195	26*26-GG	C HEAD	60*70	40
ORK-ORT-1550	TOP LINK	3	60	245	26*26-GG	C HEAD	60*70	40
ORK-ORT-1551	TOP LINK	3	68	325	26*26-GG	C HEAD	60*70	40
ORK-ORT-1552	TOP LINK	4	50	145	26*26-GG	C HEAD	63*75	40
ORK-ORT-1553	TOP LINK	4	55	195	26*26-GG	C HEAD	63*75	40
ORK-ORT-1554	TOP LINK	4	60	245	26*26-GG	C HEAD	63*75	40
ORK-ORT-1555	TOP LINK	4	68	325	26*26-GG	C HEAD	63*75	40
ORK-ORT-1556	TOP LINK	5	50	125	26*26-GG	C HEAD	70*80	45
ORK-ORT-1557	TOP LINK	5	55	175	26*26-GG	C HEAD	70*80	45
ORK-ORT-1558	TOP LINK	5	60	225	26*26-GG	C HEAD	70*80	45
ORK-ORT-1559	TOP LINK	5	68	305	26*26-GG	C HEAD	70*80	45
ORK-ORT-1560	TOP LINK	10 CAT2	50	110	26*26-GG	C HEAD WITH JOINT	90*105	50
ORK-ORT-1561	TOP LINK	10 CAT2	55	160	26*26-GG	C HEAD WITH JOINT	90*105	50
ORK-ORT-1562	TOP LINK	10 CAT2	60	210	26*26-GG	C HEAD WITH JOINT	90*105	50
ORK-ORT-1563	TOP LINK	10 CAT2	68	290	26*26-GG	C HEAD WITH JOINT	90*105	50
ORK-ORT-1564	TOP LINK	10 CAT3	50	85	26*26-GG	C HEAD WITH JOINT	90*105	50
ORK-ORT-1565	TOP LINK	10 CAT3	55	135	26*26-GG	C HEAD WITH JOINT	90*105	50
ORK-ORT-1566	TOP LINK	10 CAT3	60	185	26*26-GG	C HEAD WITH JOINT	90*105	50
ORK-ORT-1567	TOP LINK	10 CAT3	68	265	26*26-GG	C HEAD WITH JOINT	90*105	50

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.

Stock code	Product type	Capacity (t)	Closed length L (cm)	Stroke H (mm)	Pin diameter C1 - C (mm)	Type	Outer diameter D1 - D (mm)	Rod diameter d (mm)
ORK-LORT-2000	TOP LINK	2	50	195	26*26-GG		50*60	35
ORK-LORT-2001	TOP LINK	2	55	245	26*26-GG		50*60	35
ORK-LORT-2002	TOP LINK	2	60	295	26*26-GG		50*60	35
ORK-LORT-2003	TOP LINK	2	68	365	26*26-GG		50*60	35
ORK-LORT-2004	TOP LINK	2	50	195	19*26-DG		50*60	35
ORK-LORT-2005	TOP LINK	2	55	245	19*26-DG		50*60	35
ORK-LORT-2006	TOP LINK	2	60	295	19*26-DG		50*60	35
ORK-LORT-2007	TOP LINK	2	68	365	19*26-DG		50*60	35
ORK-LORT-2008	TOP LINK	2	50	195	26*26-GG	VERTICAL	50*60	35
ORK-LORT-2009	TOP LINK	2	55	245	26*26-GG	VERTICAL	50*60	35
ORK-LORT-2010	TOP LINK	2	60	295	26*26-GG	VERTICAL	50*60	35
ORK-LORT-2011	TOP LINK	2	68	365	26*26-GG	VERTICAL	50*60	35
ORK-LORT-2012	TOP LINK	2	50	195	19*26-DG	VERTICAL	50*60	35
ORK-LORT-2013	TOP LINK	2	55	245	19*26-DG	VERTICAL	50*60	35
ORK-LORT-2014	TOP LINK	2	60	295	19*26-DG	VERTICAL	50*60	35
ORK-LORT-2015	TOP LINK	2	68	365	19*26-DG	VERTICAL	50*60	35

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.

Stock code	Product type	Capacity (t)	Closed length L (cm)	Stroke H (mm)	Pin diameter C1 - C (mm)	Type	Outer diameter D1 - D (mm)	Rod diameter d (mm)
ORK-LORT-2016	TOP LINK	3	50	195	26*26-GG		60*70	40
ORK-LORT-2017	TOP LINK	3	55	245	26*26-GG		60*70	40
ORK-LORT-2018	TOP LINK	3	60	295	26*26-GG		60*70	40
ORK-LORT-2019	TOP LINK	3	68	365	26*26-GG		60*70	40
ORK-LORT-2020	TOP LINK	3	50	195	19*26-DG		60*70	40
ORK-LORT-2021	TOP LINK	3	55	245	19*26-DG		60*70	40
ORK-LORT-2022	TOP LINK	3	60	295	19*26-DG		60*70	40
ORK-LORT-2023	TOP LINK	3	68	365	19*26-DG		60*70	40
ORK-LORT-2024	TOP LINK	3	50	195	26*26-GG	VERTICAL	60*70	40
ORK-LORT-2025	TOP LINK	3	55	245	26*26-GG	VERTICAL	60*70	40
ORK-LORT-2026	TOP LINK	3	60	295	26*26-GG	VERTICAL	60*70	40
ORK-LORT-2027	TOP LINK	3	68	365	26*26-GG	VERTICAL	60*70	40
ORK-LORT-2028	TOP LINK	3	50	195	19*26-DG	VERTICAL	60*70	40
ORK-LORT-2029	TOP LINK	3	55	245	19*26-DG	VERTICAL	60*70	40
ORK-LORT-2030	TOP LINK	3	60	295	19*26-DG	VERTICAL	60*70	40
ORK-LORT-2031	TOP LINK	3	68	365	19*26-DG	VERTICAL	60*70	40

All dimensions in mm unless stated otherwise. Sizes not listed are made to drawing or sample.

Quote & Contact

Send a drawing, sample or dimensions — we review manufacturability and prepare a quote.
